Cicor's PCBA Prototyping Shop - Fast and flexible solutions for developers
Developers often face the challenge of realising new designs within a short time frame. With Cicor's PCBA Prototyping Shop, we offer you an efficient and flexible solution to complete your projects on time. You can simply upload the parts list, PCB and pick-and-place data and specify the exact components in the tool. At the same time, the market availability of the components is checked. Once all the data is complete, the system calculates the price automatically. After confirmation, procurement and production start immediately and you can track the status of your order at any time in the customer portal. Thanks to the integrated comment function, we are on hand to answer any queries you may have. You also have an overview of your projects at all times and can manage them conveniently. We manufacture your assemblies from 6 working days including material procurement - precisely and reliably. Rely on our global expertise to accelerate your innovation processes.
Technical Specifications
| |
| Production according to: | IPC 610-A, Class 2 |
| PCB panel size: | minimal: 70mm x 70mm ² / maximal: 410mm x 350mm |
| PCB material and thicknesses: | FR4 with material thicknesses of (0.8mm) / 1mm ... 3mm for rigid-flex PCB thickness from 200µm |
| PCB Finish: | chem. nickel-gold / HAL lead-free / chem. tin |
| PCB solder resist / labelling: | green / labelling print (partial) |
| Lot size: | up to 20 pieces ² |
| Manufacturing process: | SMT (one- or two-sided) see optional options further down |
| Assembly of component sizes up to: | 0201 (Imperial) |
| Solders / pastes used: | SAC305 (reflow processes) |
² Larger sample quantities possible by prior arrangement
Drawing data / parts list
To ensure that your prototype enquiry is processed smoothly, please provide us with the following information:
- All data in a .zip folder
- Gerber or ODB++ files including PCB specifications (layer structure, thickness, etc.)
- The panel drawing (optional) must have 3 identification marks
The parts list must be in a machine-readable format, preferably Excel format (example file available for download).
Options
Note: These additional services usually extend the delivery time (depending on the complexity of the assembly).
Order conditions
Terms and conditions
As soon as the plausibility check has been successfully completed, you will automatically receive a quotation. For production, the parts list, the CAD data of the PCB and the pick-and-place data (P&P) must be available in full.
The delivery time for assembled rigid or rigid-flexible PCBs can be from 6 working days, depending on the respective requirements, material availability or any materials provided. After production release, changes are no longer possible.
A seamless transition to series production within the Cicor Group is possible without any problems .
Payment and dispatch
Payments can be made conveniently by invoice or credit card. Delivery is made with Incoterm DAP.
The goods are packed in standard, ESD-compliant packaging with appropriate filling material to ensure the safe arrival of the goods.
